3 Roll Pyramid type Mechanical Plate Bending Machine

Features:

The PBM series 3 Roll Pyramid Type Mechanical Plate bending are designed to cater the basic requirements of bending & forming of metal plates. In this machine, the bottom rolls are driven by electric motor & gear box. The upper roll is having manual up & down adjustment to achieve desired bending radius. This is a very simple & robust design machine suitable for light to medium jobs.

PBM SERIES (HYDRO-MECHANICAL)

  • 3 roll PYRAMID type design machine
  • The robust welded structure is made of UT tested IS:2062 M.S. plates
  • The top roll adjustment is by Hydraulic Cylinder
  • Bottom rolls are power driven
  • Bending rolls are made of alloy steel

PBM SERIES (MECHANICAL)

  • 3 roll PYRAMID type design machine
  • The robust welded structure is made of UT tested IS:2062 M.S. plates
  • The top roll adjustment is by Screw Jack
  • Bottom rolls are power driven
  • Bending rolls are made of alloy steel

PBM SERIES (HYDRO-MECHANICAL)

Standard Accessories

  • Main drive motor
  • Reverse / Forward roll drive with overload protection
  • Manual Centralized lubrication system
  • Gearbox attached with Electric Motor
  • Hydraulic end dropper arrangement

Optional Accessories

  • Hardened Rolls
  • Grounded Rolls
  • Automatic lubrication system
  • Extended shaft with profile bending rolls
  • Conical bending arrangement
  • Material feed table
  • Digital Readouts

PBM SERIES (MECHANICAL)

Standard Accessories

  • Main drive motor
  • Reverse / Forward roll drive with overload protection
  • Manual Centralized lubrication system
  • Gearbox attached with Electric Motor
  • Manual end dropper arrangement

Optional Accessories

  • Hardened Rolls
  • Grounded Rolls
  • Automatic lubrication system
  • Extended shaft with profile bending rolls
  • Conical bending arrangement
  • Material feed table
  • Digital Readouts
