Box type Geared Drive – Auto Feed Work Table

Model : ZAY7032A/1..
  • Worktable auto – feeding X ,Y
  • Spindle speed – change cyclically and spindle auto – feeding and cyclic change of feeding speed
  • Milling, drilling, tapping, boring and roaming
  • Head swivels ± 90° vaetically
  • Micro feed precision
  • Adjustable gibs on table precision
  • Strong rigidity power cutting andprecise positioning.
MODELZAY7032A/1ZAY7040A/1ZAY7045A/1
Drilling capacityø32mmø40mmø45mm
Max. Boring Diameterø50mmø60mmø70mm
Max. Face mill capacityø63mmø80mmø80mm
Max. End milling capacityø20mmø32mmø32mm
Max. Distance from spindle nose to table400mm400mm400mm
Min. distance from spindle axis to column260mm260mm260mm
Spindle travel130mm130mm130mm
Spindle taperM.T.3, M.T.4M.T.3, M.T.4M.T.3, M.T.4
Step of spindle speed666
Range of spindle speed 50Hz80-1250 r.p.m80-1250 r.p.m80-1250 r.p.m
Swivel angle of headstock (Perpendicular)± 90°± 90°± 90°
Auto Feeding step of spindle (longitudinal / Cross)666
Auto Feeding amount of Worktable24,35,49,73,104,145mm/min24,35,49,73,104,145mm/min24,35,49,73,104,145mm/min
Table size800x240mm800x240mm800x240mm
Forward and backward travel of table165mm165mm165mm
Left and right travel of table450mm450mm450mm
Motor power0.75KW1.1KW1.5KW
Net weight355kgs/415kgs358kgs/418kgs360kgs /420kgs
Packing size (LxWxH)930x770x1160mm930x770x1160mm930x770x1160mm

Standard Accessories :

  • Allen wrench
  • Wedge
  • Tie Rod
  • Drill Chuck
  • Milling cutter holder
  • Mill Chuck
  • Working Lamp
  • Coolant System
  • Machine Stand
  • Changing Sleeve
  • Parallel Vise
  • Boring Bar
  • Auto Tapping Arrangement
