Box type Geared Drive – Auto Feed
Model : ZAY7032FG/1...

- Spindle speed – change cyclically and spindle auto feeding and cyclic change of feeding speed.
- Milling, drilling, tapping, boring and roaming
- Head swivels ± 90° vertically
- Micro feed precision
- Adjustable gibs on table precision
- Strong rigidity powerful cutting and precise positioning.
MODEL | ZAY7032FG/1 | ZAY7040FG/1 | ZAY7045FG/1 |
---|---|---|---|
Drilling capacity | ø32mm | ø40mm | ø45mm |
Max. Boring Diameter | ø50mm | ø60mm | ø70mm |
Face milling capacity | ø63mm | ø80mm | ø80mm |
End milling capacity | ø20mm | ø32mm | ø32mm |
Max. Distance from spindle nose to table | 450mm | 450mm | 450mm |
Min. distance from spindle axis to column | 260mm | 260mm | 260mm |
Spindle travel | 130mm | 130mm | 130mm |
Spindle taper | M.T.4 | M.T.4 | M.T.4 |
Step of spindle speed | 6 | 6 | 6 |
Range of spindle speed 50Hz | 80-1250 r.p.m | 80-1250 r.p.m | 80-1250 r.p.m |
Swivel angle of headstock (perpendicular) | ± 90° | ± 90° | ± 90° |
Automatic lifting of Spindle | 240mm/min | 240mm/min | 240mm/min |
Table size | 800x240mm | 800x240mm | 800x240mm |
Forward and backward travel of table | 175mm | 175mm | 175mm |
Left and right travel of table | 500mm | 500mm | 500mm |
Motor power | 0.75KW | 1.1KW | 1.5KW |
Net weight | 320kgs/370kgs | 323kgs/373kgs | 325kgs/375kgs |
Packing size (LxWxH) | 770x880x1160mm | 770x880x1160mm | 770x880x1160mm |
Standard Accessories :
- Allen wrench
- Wedge
- Tie Rod
- Drill Chuck
- Milling cutter holder
- Mill Chuck
- Working Lamp
- Coolant System
- Machine Stand
- Changing Sleeve
- Parallel Vise
- Boring Bar
- Auto Tapping Arrangement
