Extra Heavy Duty lathe (Roll Turning Lathe)

Model : RL Series

Features:

  • High Tensile Casting
  • Latest Design Head Stock
  • It is one of the heavy duty tools that have been constructed with high grade and strong materials like iron and steel.
  • We have equipped one of the latest head stock designs for this equipment for the users to experience precise, fast and reliable lathe performance.
  • It is highly industrial friendly and would stay an efficient choice of investment for your industries.
  • Our this instruments are preferred in several industries for its robust structure, reliability, accuracy in machining and above all for pricing.

Plano Type Bed

ModelsRL45RL50RL55RL60RL65RL70RL75RL85RL95RL115
Bed Length FL12’14’16'18'20'22'24'30'36'40'
Admit between Centre24003000345037504350495055507350885010050
Height Of Centre (mm)4505005506006507007508509501150
Width Of Bed (mm)50055060065070075080090010001200
Over Bad900100011001200130014001500170019002300
In Gap1500160017001800190020002100230025002650
Bore (mm)4"4"4"4"4"4"4"4"4"4"
Speed - 8 (R.P.M.)6666666666
Lead Screw Dia2"2"2''2 1/2''2 3/4''2 3/4''3''3''3 1/2 ''4 1/2 ''
Power Required (H.P.)55557 1/21015202525

Standard Accessories :

  • Chuck Plate
  • Gear Set
  • Centre Adaptor
  • Dead Centres
  • Dial Indicator
  • Square Tool Post
  • Tool Post Key
  • Steady Rest
  • Follow Rest
  • Face Plate

Optional Accessories :

  • Steady Rest
  • Follow Rest
  • Face Plate
  • Electrical Fittings
  • True Chuck & Dog Chuck
  • Quick Change Tool Post
  • Tapper Turning Attachment
  • Coolant Pump with Tank & Fittings
  • Machine Lamp
  • Tool Post Grinder
