Light Duty All Geared Lathe – PRH-170

Model : PRH - 170

Features:

  • High Tensile Casting
  • Latest Design Head Stock
  • Hardened & Ground Bed & Spindle
  • The device is designed for handling variety of light weight materials like metal sheets, wood sheets, etc.
  • Bhavya Machine Tools presents light duty tool that is created considering the current machining norms required by industries.
  • This equipment is featured with non-slippage formula that prevents work materials from de-positioning at the time of machining.
  • It is compatible to work with variety of materials.
  • It is highly reliable, consistent and strong for machining requisites over long run.
  • Machining operations stay accurate, precise, flawless and uninterrupted.
  • Provided with excellent selection of standard accessories.
  • Consumers will have more optional accessories to choose from.
  • Pricing is competitive.
ModelPRH-170
Height Of Center170 mm
Swing Over Bed340 mm
Swing Over Slide180 mm
Width Of Bed240 mm
Spindle Bore40 mm
Spindle NoseLoo Type
Speed No - 8 (RPM)60 to 1025
Cross Slide175 mm
Top Slide125 mm
Quil Dia/ Travel50 /125
Lead Screw4 TPI.
Tail Stock SleeveMT-3
Main Motor Power2 HP
Bed LengthA.B.C
4.5'600 mm
5'750 mm

Gear Box with Lead Screw & Feed Shaft Separate

Standard Accessories :

  • Chuck Plate
  • Gear Set
  • Center Adaptor
  • Dead Centers
  • Dial Indicator
  • Square Tool Post
  • Tool Post Key

Optional Accessories :

  • Steady Rest
  • Follow Rest
  • Face Plate
  • Electrical Fittings
  • True Chuck & Dog Chuck

  • Quick Change Tool Post Tapper Turning Attachment
  • Coolant Pump with Tank & Fittings Machine Lamp
  • Rear Tool Post
  • Key way Milling Attachment
  • Tool Post Grinder
