Mechanical Shearing Machine (Overcrank)

Standard Accessories
- Foot Paddle
- Fly Wheel& Gear Guard
- A Pair of Four edge Shear Blade
- Self Lubrication System
- Motor Pulley
- Front Gauge
- Back Gauge
Optional Accessories
- Motorized Back Gauge
- Automatic Lubrication System
- Squaring Gauge System
- Vee-Belt
- Electric Motor & Starter/ Control Panel Board
- Extension Squaring Arm
- Foundation Bolts
Model | Cutting CAP. in MS Length x Thickness | Stroke per Minute | Table Height | Table Width | Front Gauge | Rear Gauge | Motor HP |
---|---|---|---|---|---|---|---|
TOS-126 | 1270×6 | 30 | 825 | 460 | 980 | 750 | 7.5 |
TOS-156 | 1525×6 | 30 | 825 | 460 | 980 | 750 | 10 |
TOS-206 | 2030×6 | 30 | 825 | 460 | 980 | 750 | 12.5 |
TOS-256 | 2540 x6 | 30 | 825 | 460 | 980 | 750 | 12.5 |
TOS-316 | 3150×6 | 30 | 825 | 460 | 980 | 750 | 15 |
TOS-128 | 1270×8 | 30 | 825 | 460 | 980 | 750 | 10 |
TOS-158 | 1525×8 | 30 | 825 | 460 | 980 | 750 | 10 |
TOS-208 | 2030×8 | 30 | 825 | 460 | 980 | 750 | 12.5 |
TOS-258 | 2540 x 8 | 30 | 825 | 460 | 980 | 750 | 15 |
TOS-318 | 3150×8 | 30 | 825 | 460 | 980 | 750 | 20 |
TOS-1210 | 1270x 10 | 25 | 800 | 450 | 1000 | 750 | 10 |
TOS-1510 | 1525x 10 | 25 | 800 | 450 | 1000 | 750 | 12.5 |
TOS-2010 | 2030x 10 | 25 | 800 | 450 | 1000 | 750 | 15 |
TOS-2510 | 2540×10 | 25 | 800 | 450 | 1000 | 750 | 20 |
TOS-3110 | 3125×10 | 25 | 800 | 450 | 1000 | 750 | 25 |
TOS-1212 | 1270x 12 | 25 | 800 | 450 | 1000 | 750 | 12.5 |
TOS-1512 | 1525x 12 | 25 | 800 | 450 | 1000 | 750 | 15 |
TOS-2012 | 2030x 12 | 25 | 800 | 450 | 1000 | 750 | 20 |
TOS-2512 | 2540x 12 | 25 | 800 | 450 | 1000 | 750 | 25 |
TOS-3112 | 3125×12 | 25 | 800 | 450 | 1000 | 750 | 30 |
Over Crank Mechanical Shearing Machine
Bhavya Machine Tools offers over crank mechanical shearing machine. They are widely used for cutting large sheets, bars and plates of metallic and non-metallic materials into various shapes. Our machines are designed for faster and precise cutting. We supply latest, sturdy and durable shearing machines. The main features include better safety, low maintenance and higher productivity. These machines comply with standard quality control norms. Our shearing machines are built to minimize material wastage. They are engineered for continuous and repeated production. We provide various models with different technical specifications. Shearing machines are used in automobile, printing, food processing, engineering, electronic, plastic, wood working, electrical, construction and several other industries.
