Pneumatic Type Power Press

Model : BNCP-10,..
Pneumatic Type Power Press
Model No BNCP-10 BNCP-20 BNCP-30 BNCP-40 BNCP-50
Capacity in Tons (mm) 10 20 30 40 50
Crankshaft Diameter (mm) 88 115 130 135 140
Adjustment of Stroke (mm) 15×50 15×63 76 76 89
Adjustment of Ram (mm) 25 25 25 25 25
Punch Hole in Ram (mm) 25 32 38 38 45
Hole in Bed (mm) 76 82 89 95 101
Bed Size (Length x Width) (mm) 432 x 228 534×305 585×355 635 x 355 685×406
Bed Thickness (mm) 58 63 70 76 83
Dist. between bed to Ram (mm) 204 250 292 320 350
Flywheel Dia. (mm) 458 482 533 584 660
Strokes per minute (mm) 70 55 50 45 45
Motor Power (HP)-1440 RPM 1.5 2 3 4 5
Air Pressure Required (BAR) 5.5 5.5 5.5 5.5 5.5
Floor To Top of Bed (mm) 830 830 880 1000 1000
Model No BNCP-60 BNCP-80 BNCP-100 BNCP-150 BNCP-200 1
Capacity in Tons (mm) 60 80 100 150 200
Crankshaft Diameter (mm) 150 160 170 190 250
Adjustment of Stroke (mm) 100 115 130 150 150
Adjustment of Ram (mm) 25 25 25 25 25
Punch Hole in Ram (mm) 45 50 50 80 80
Hole in Bed (mm) 115 130 150 200 225
Bed Size (Length x Width) (mm) 712 x 457 738 x 508 891 x 612 1041 x 737 1100 x 817
Bed Thickness (mm) 88 95 114 127 137
Dist. between bed to Ram (mm) 380 380 406 457 482
Flywheel Dia. (mm) 762 812 863 965 1016
Strokes per minute (mm) 40 40 35 30 25
Motor Power (HP)-1440 RPM 7.5 10 10 12.5 15
Air Pressure Required (BAR) 5.5 5.5 5.5 5.5 5.5
Floor To Top of Bed (mm) 100 1000 1000 1000 1000

Design, Dimension & Specifications are subject to change without prior notice.

* All dimensions are in mm
