Shaping Machine (Hydraulic)

Model : TCS-12-H, TCS-18-H

Features

  • Hydraulic Power pack unit complete with electric motor 2 H.P
  • hydraulic vane pump
  • solenoid operated direction control valves
  • pressure relief valve
  • Flow Control Valves
  • Speed Control Valves
  • accessories
  • analogue pressure gauges and all safety factors
MODELTCS-12-HTCS-18-H
SIZE305mm457 mm
Length of ram storke660mm960 mm
Length of ram520x203700x270 mm
Length of width ram bearing257/40mm360 / 75 mm
Max /min distance of table to ram305 x 203457x305 mm
Working surface of table -60L 60R60L 60R
Angular movement of table140 mm152 mm
Max vertical table travel -60L 60R60L 60R
Max swivel of tool head -ManualManual
Tool head feed2 hp2 hp
Motor80 Itr80 Itr
Hydrolic tank capacity650 kgs1200 kg
