Tapping Machine(BPT)

Model : BPT-5, BPT-12, BPTH-6
  • Column, Arm, Work Head & Gears are made out of Closed Grain.
  • Parts Properly Balanced
  • Prior Assembling of Main Gear & Pully
  • Parts Finished on imported Grinding Machine
  • All moving parts Finished to close Tolerance
  • Spindle Ram is made out of Alloy Steel.
  • Main Spindle & Pinon are Made out of EN Forged Steel.
ModelBPT-5BPT-12BPTH-6
Drilling in M.S--6
Tapping in Steel5mm12mm-
Tapping in C.I.7mm12mm-
Tapping Depth-15-
Spindle Travel--57
No. of Spindle Speed8-2
Range of Spindle Speed590-1680-5000-10000
Table Stroke-55-
Max. / Min Dist Between Spindle Center104150155
to Coloumn Face
Max. Dist Between Spindle Nose to Table140335225
Face
Max./ Min Dist Between Spindle Nose to--430
Base
Diameter of Coloumn46.8063.5046.80
Size of Working Table168x168265 x 265220 x 220
Size of Base Plate380 x 250430 x 300265 x 385
Drilling Head Motor0.5 H.P/1440 RPM1 H.P/1440 RPM0.5 H.P/ 2800 RPM
