Vertical Fine Boring & Facing Machine

Model : MB-1170, MBM-1170
Vertical Fine Boring & Facing Machine
Model MB 1170 - MBM-1170
Boring Capacity 65 - 150mm
Boring Head Travel 550 mm
Spindle Speeds 50 to 350 RPM
Spindle Feed per Revolution 0.06, 0.10 & 0.15 mm
Max. dist from Spindle Center Line
to colum 375 mm
Max. dist from table to head 1100 mm
Working Table Size (L x W) 1170 x 450mm
Table Traverse - Longitudinal 1100 mm
Table Traverse - Crosswise 50 MM
Max Milling Length (MBM 1170) 1100 mm
Max Milling Width (MBM 1170) 250 mm
Automatic Table feed 0-250 mm/ min
Motor - Spindle Drive 2 HP
Motor - Table Displacement (MBM 1170) 0.25 HP
