Description
| Model | BMTU/300/100 |
| Center Height | 100mm |
| Distance Between Centers | 300mm |
| Table Swingle Degree | +10 Deg./4 Deg. |
| Table Speed Infinitely Variable | 0.1 – 2.5m/min. |
| Hydraulic Power Pack Motor | 0.5HP-1440rpm |
| Grinding Wheel (D x W x B) | 350 x 25 x 76.2mm |
| Grinding Wheel Speed | 1900rpm |
| In feed of Hand Wheel | 0.01mm /Div. |
| Grinding Head Motor | 2HP-1440rpm |
| Rapid Approach | 40mm |
| Range of work Head Speed | 90-180-360rpm |
| Work Head Spindle Taper | MT-3 |
| Work Head Motor Power | 0.5HP-960rpm |
| Tail Stock Spindle Taper | MT-3 |
| Tail Stock Quill Stroke | 25mm |
| Coolant Tank | 35 Liter |
| Coolant Pump Motor | 0.15HP |
| Approx. Machine weight | 900kg |
*Specifications are subject to changed without prior notice.
