Description
Specification
Salient Features:
- Stress Relieved Fabricated Steel Structure
- Hard Chrome Plated Ground Column
- Automatic Height Adjustment for Saw Frame
- Variable Pressure Control for Cutting Feed
- Auto Cutting Stop
- Push Button Type Operating Panel Board
- Heavy Duty Worm Gear Box
- Moveable Blade Support Guide
- Manual Blade Tensioning Arrangement
- Material Feeding Manually
Standard Accessories:
- Saw Blade
- Coolant Systems
- Machine Lamp
- Blade Tensioning Wrench
- Adjustable Bar Support Stand
- Tool Kit
- Operating & Instruction Manual
| Model | BDH-200 |
| Cutting Capacity Round | 200mm |
| Cutting Capacity Square | 200 x 200mm |
| Blade Size | 2800 x 27 x 0.9mm |
| Blade Speed | 27,45, 69m/min. |
| Clamping Type | Hydraulic |
| Main Motor Power | 1.5kW |
| Hydraulic Motor Power | 0.55kW |
| Coolant Motor | 0.04 kW |
| Power Supply | 415V-50Hz-3Phase |
| Overall Dimension | 1400 x 900 x 1100mm |
