Salient Features:
- Stress Relieved Fabricated Steel Structure
- Hard Chrome Plated Ground Column
- Automatic Height Adjustment for Saw Frame
- Variable Pressure Control for Cutting Feed
- Auto Cutting Stop
- Push Button Type Operating Panel Board
- Heavy Duty Worm Gear Box
- Moveable Blade Support Guide
- Manual Blade Tensioning Arrangement
- Material Feeding Manually
Standard Accessories:
- Saw Blade
- Coolant Systems
- Machine Lamp
- Blade Tensioning Wrench
- Adjustable Bar Support Stand
- Tool Kit
- Operating & Instruction Manual
| Model | BDH700A |
| Cutting Capacity Round | 700mm |
| Cutting Capacity Square | 700 x 700mm |
| Blade Size | 7205 x 54 x 1.6mm |
| Blade Speed | 27,45, 69m/min. |
| Clamping Type | Hydraulic |
| Main Motor Power | 5.5kW |
| Hydraulic Motor Power | 1.1kW |
| Coolant Motor | 0.125kW |
| Power Supply | 415V-50Hz-3Phase |
| Overall Dimension | 3500 x 1800 x 2500mm |
