Description
Standard Accessories:
- Chuck Plate
- Gear Set
- Centre Adaptor
- Dead Centers
- Dial Indicator
- Square Tool Post
- Tool Post Key
Optional Accessories:
- Steady Rest
- Follow Rest
- Face Plate
- Electrical Fittings
- True Chuck & Dog Chuck
- Rear Tool Post
- Tool Post Grinder
- Norton Gear Box
- Key Way Milling Attachment
- Quick Change Tool Post
- Taper Turning Attachment
- Coolant Pump with Tank Fittings
- Machine Lamp
- Big Spindle Bore (On Request)
| Model | MAX |
| Height Of Centre (mm) | 250 |
| Width Of Bed (mm) | 325 |
| Max. Swing (mm) | |
|---|---|
| Over Bed | 500 |
| Over Slide | 300 |
| In Gap | 775 |
| Spindle | |
| Bore (mm) | 52 |
| Nose | 6 TPI |
| Speed-8 (R.P.M) | 30 to 475 |
| Travel (mm) | |
| Cross Slide | 270 |
| Top Slide | 150 |
| Other | |
| Lead Screw TPI | 4 TPI |
| Tail Stock Sleeve | MT-4 |
| Power Required (H.P.) | 3 |
