CKE Series Flat Bed CNC Lathe (CKE6126L - CKE6140)

Model : CKE6126L,CKE6140
CKE Series Flat Bed CNC Lathe (CKE6126L – CKE6140)
Models CKE6126L/300mm CKE6136 / CKE6136Z CKE6140/CKE6140Z
Max. Swing Over Bed 260mm 360mm 400mm
Max. Swing over Slide 140mm 180mm 200mm
Max. Length of Work 300mm 750mm/1000mm 750mm/1000mm
Width of Bed 220mm 300mm 300mm
Travel /Rapid
X Travel 165mm 205mm 225 mm
Z Travel 260mm 620/870mm 620/870mm
Rapid traverse (X-Axis) 20m/min 4m/min 4m/min
Rapid traverse (Z-Axis) 20m/min 5m/min 5m/min
Spindle Nose A2-5 D6 D6
Chuck size 165mm (Solid) 200mm 200
Taper of Spindle bore M5 M6 M6
Spindle Bore 40mm 52mm 52mm
Spindle Speed - Frequency Motor (Servo Motor in 1-Series) 40-4000rpm 20-650rpm
Steps of spindle speed Steepless 2 - Step Actuator 2 - Step Actuator
Motor Power 5.5kW 5.5kW 5.5kW
Tool Post
Repeatability of tool post 0.008mm 0.008mm 0.008mm
Vertical 4-position Toolpost changing time 2.1 Sec. 2.4 Sec. 2.4 Sec.
Horizontal 6-position Toolpost changing time 3.0 Sec. 3.0 Sec
Tail Stock
Diameter of tailstock quill N/A 63mm 63mm
Travel of tailstock quill N/A 130mm 130mm
Taper of tailstock quill N/A M4 M4
Weight & Dimensions
Net weight 900Kg 1850Kg./1950Kg. 1850Kg./1950Kg.
Dimensions (Length x Width x Height) 600mm 1800x1500x1750mm
750mm   2300x1480x1520mm 2300x1480x1520mm
1000mm   2550x1480x1520mm 2550x1480x1520mm
