CKE Series Flat Bed CNC Lathe (CKE6150-CKE6166)

Model : CKE6150, CKE6166
DMTG CKE Series Flat Bed CNC Lathe (CKE6150-CKE6166)
Models CKE6150/CKE6150Z CKE6156/CKE6156Z CKE6166Z
Max. Swing Over Bed 500mm 560mm 660mm
Max. Swing over Slide 280mm 330mm 430mm
Max. Length of Work 750/1000/1500/2000 mm 750/1000/1500/2000 mm 750/1000/1500/2000 mm
Width of Bed 400mm 400mm 400mm
Travel /Rapid
X Travel 280mm 305mm 305mm
Z Travel 680/930/1430/1930 mm 680/930/1430/1930 mm 680/930/1430/1930 mm
Rapid traverse (X-Axis) 6m/min 6m/min 5m/min
Rapid traverse (Z-Axis) 10m/min 10m/min 10m/min
Spindle Nose D8 D8 D8
Chuck size 250mm 250mm 315mm
Taper of Spindle bore 1:20 1:20 1:20
Spindle Bore 82/100mm 82/100mm 82/100mm
Spindle Speed - Frequency Motor (Servo Motor in 1-Series) 7-135rpm
Steps of spindle speed 3 - Step Actuator 3 - Step Actuator 3 - Step Actuator
Motor Power 7.5kw 7.5kw 7.5kw
Tool Post
Repeatability of tool post 0.008 mm 0.008mm 0.008mm
Vertical 4-position Toolpost changing time 2.4 Sec. 2.4 Sec. 2.4 Sec.
Horizontal 6-position Toolpost changing time 3.0 Sec. 3.0 Sec. 3.0 Sec.
Tail Stock
Diameter of tailstock quill 75mm 75mm 100mm
Travel of tailstock quill 150 mm 150mm 150mm
Taper of tailstock quill M4 M5 M5
Weight & Dimensions
Net weight 2550Kg/2600Kg./2700Kg./2800Kg. 2600Kg./2650Kg./2750Kg./2850Kg. 2700Kg./2750Kg./2850Kg./2950Kg.
Dimensions (Length x Width x Height) 600mm 2580x1750x1620mm 2580x1750x1620mm 2580x1750x1700mm
750mm 2830x1750x1620mm 2830x1750x1620mm 2830x1750x1700mm
1000mm 3330x1750x1620mm 3330x1750x1620mm 3330x1750x1700mm
1500mm 3830x1750x1620mm 3830x1750x1620mm 3830x1750x1700mm
