Fiber Laser Marking Machine

YLH-20L Fiber Laser Marking Machine's working principle is that to make use of fiber laser to generate laser and export the laser with optical fiber and then cooperate with optical high-speed scanning galvanometer for workpiece marking, the core of which is fiber laser source.

Fiber lasers use rare earth doped fibers as the gain medium. Due to the fine fiber core in the fiber laser, it is easy to form a high power density in the fiber under the action of the pump light, resulting in a laser energy level "inversion of the number of particles" of the laser working substance. Therefore, the laser oscillation can be formed when the positive feedback loop is properly formed to form the resonant cavity. In addition, because the fiber matrix has a wide spectrum of fluorescence, fiber lasers are generally made to be tunable (ie. their wavelength can be adjusted within a certain range). Some core features are as below:

  • Long using lifetime, the machine can be used for 100,000 hours
  • Energy saving:Small size& low power consumption, the whole power consumption less than 500W;
  • High Efficiency for photoelectric conversion, compact in structure ,high system integration, fewer faults,no consumables.
  • High processing Speed without deviation , the speed can be 12000mm/s.
  • Powerful Software andcompatible with the filesofCoreldraw, AutoCAD and other software. Support PLT, PCX, DXF, BMP, etc., can directly use SHX and TTF fonts;
  • Widely application,it can mark logo, words, brand, date, series Number, batch number, sign, drawing, photo, QR code etc on the metal material (like stainless steel, alloy, metal plate, aluminum , silver, gold etc.) and non-metal material (like plastic: engineering plastic and hard plastic, etc. Used in electronic components integrated circuits, mobile communications, precision instruments, glasses watch and clocks, computer keyboard, accessories, auto parts, plastic buttons, plumbing fittings, sanitary ware, PVC pipe, medical equipment, packaging bottles, battery, craft etc )
Laser TypeFiber (Co2 also available)
Laser SourceRAYCUS
Power20W (30W, 50W, 100W can be optional)
Work Precision±0.01mm
Max Marking Speed12,000 mm/s
Support FormatPLT, DST, AI, DXF, BMP, JPG, CAD,CDR, DWG,PCX
SoftwareJCZ EZCAD 2.12 Professional
Cooling WayAIR COOLED
Power Regulation Scope1% - 100%
Power Consumption<=500W
Work Area (mm)110x110 / 175X175 (Customized)
Min Line Width0.017mm
Min Character0.2mm X 0.2mm
Wave Length1064nm
Laser Module Life1,00,000 Hours
Laser Repetition Frequency20LHz - 80KHz(Adjustable)
Power RequirementAC220V / 50HZ / 2A
Output Working Temperature13-30 C
Marking Depth0.01-1.0mm(Subject to material)
  • The fiber laser generator is highly integrated, has superior laser beam and uniform power density. Output laser power is stable. This design highly increases the machine’s anti-reflection ability with optical isolator, be able to mark on most high reflective materials such as aluminum, copper, gold and silver without the shadow and virtual open phenomenon.
  • Adopts advanced digital high speed scanning galvanometer, quick speed without deviation, small volume, good stability, and performance reached the international advanced level.
  • Modular design, separate laser generator and lifter, more flexible, can mark on bigger area and complicated surface. Air-cooled inside, small occupation, easy to install.
  • Adopt the embedded operating system, which the performance is leading domestic peers, good touch interface and powerful control system, can meet the demand of most industry application process in market.
  • High efficiency for photoelectric conversion, simple operation, Compact in structure, support harsh working environment, no consumables.
  • YLH-20L Desktop fiber laser marking machine is a standard type in the whole fiber laser marking machine series. Its classical design stands popular since laser marking machine’s invention.

Precision instruments, computer keyboards, auto parts, plumbing parts, communications equipment, medical equipment , bathroom equipment, hardware tools, luggage decoration, electronic components, home appliances, watches, molds, gaskets and Seals, data matrix, jewelry, cell phone keyboard, buckle, kitchenware, knives, cooker, stainless steel products, aerospace equipment, integrated circuit chips, computer accessories, signs molds, elevator equipment, wire and cable , Industrial bearings, building materials, hotel kitchen, military, pipelines.

Tobacco industry, bio-pharmaceutical industry, liquor industry, food packaging, beverage, health care products, plastic buttons, bathing supplies, business cards, Clothing accessories, cosmetics packaging, car decoration, wood, logos, characters, serial number, bar code, PET, ABS, pipeline, advertising logo and other non-metallic industries.
