V-Belt Drive Lathe Machine
Light Duty Lathe V-Belt Drive (LD 175, MD212 and MD212H)

Light Duty Lathe V-Belt Drive (LD 175, MD212 and MD212H)

High Tensile

Casting

Head Stock

Latest Design

Bed & Spindle are

Hardened & Ground

LATHE

Model No

LD 175
MD 212
MD 212H

Get A Quote

Technical Specifications

Model	LD 175	MD 212	MD 212H
Height Of Center (mm)	175	212	250
Width of Bed (mm)	238	280	280
Max. Swing Over Bed (mm)	350	410	490
Max. Swing Over Slide (mm)	200	240	320
Spindle Bore (mm)	40	52	80
Spindle Nose	8 ΤΡΙ	6 ΤΡΙ	6 ΤΡΙ
Spindle Speed (R.P.M.)	30-825	40 To 550	40 To 550
Cross Slide Travel (mm)	225	240	240
Lead Screw TPI	4 ΤΡΙ	4 ΤΡΙ	4 ΤΡΙ
Tail Stock Sleeve	MT-3	MT-4	MT-4
Power Required (H.P.)	1	2	2

Admit Between Centers

Length	A.B.C (LD 175)	A.B.C (MD 212, 212H)
4.6'	650 mm	500 mm
5.3'	875 mm	725 mm
6'.0"	1050 mm	950 mm
7'.0"	-	1250 mm

*Specifications are subject to changed without prior notice.

Accessories

Standard :

Chuck Plate
Gear Set
Centre Adaptor
Dead Centers

Dial Indicator
Square Tool Post
Tool Post Key

Optional :

Steady Rest
Follow Rest
Norton Gear Box
Electrical Fittings
True Chuck & Dog Chuck
Quick Change Tool Post
Tapper Turning Attachment
Knob Type Oil Bath Norton Gear Box

Coolant Pump with Tank & Fittings
Face Plate
Machine Lamp
Rear Tool Post
Key way Milling Attachment
Tool Post Grinder
Plunger Type Norton Gear Box

Features

High Tensile Casting
Latest Design Head Stock
Hardened & Ground Bed & Spindle

Photo Gallery

LD - Standard Model

LD - Super Model

MD - 212, 212H
