Medium Duty Lathe (SuperModel)

Model : MD Series

Features:

  • High Tensile Casting
  • Latest Design Head Stock
  • Hardened & Ground Bed & Spindle
  • Norton Gear Box With Lead Screw & Feed Shaft Seprate
  • It is made of strong construction that allows the user to experience precise machining and fast performance.
  • The V-belt feature allows for fast performance ratio and consistent production on long run.
  • Precision is guaranteed.
  • Maintenance aspects are easy and convenient.
  • Produces comparatively lesser noise during machining.
  • This equipment can be installed easily and stays perfect for moderately spaced workshops.
  • Equipped with excellent working platform to handle work materials conveniently.
  • Stays efficient for shaping requisites in wide range of industries.

Super Model

ModelsMD 212MD 212H
Height Of Centre (mm)212250
Width of Bed (mm)280280
Max Swing over bed (mm)410490
Max Swing over Slide (mm)240320
Spindle Bore (mm)52 mm80 mm
Spindle Nose6 TPI6 TPI
Spindle Speed 6 (R.P.M)40 to 55040 to 550
Cross Slide Travel (mm)240 mm240
Lead Screw TPI4 TPI4 TPI
Tail Stock SleeveMT-4MT-4
Power Required (H.P.)22

Admit Between Centers

LengthA. B. C
4.6'500
5.3'725
6'.0''950

Standard Accessories :

  • Chuck Plate
  • Gear Set
  • Dial Indicator
  • Square Tool Post
  • Tool Post Key

Optional Accessories :

  • Steady Rest
  • Follow Rest
  • Face Plate
  • Electrical Fitting
  • True Chuck & Dog Chuck
  • Quick Change Tool Post
  • Steady Rest
  • Follow Rest
  • Face Plate
  • Electrical Fitting
  • True Chuck & Dog Chuck
  • Quick Change Tool Post
