Pillar Drilling Machine 40mm

Model : BPSL-40A, BPSL-40, BPRL-40A
Pillar Drilling Machine 40mm
Model BPSL-40A* BPSL-40 BPRL-40
Machine Capacity (mm) 40mm 40mm 40mm
Column Diameter (mm) 135mm 121mm 121mm
Center of Spindle to Column (mm) 380mm 320mm 320mm
Distance Spindle to Table (mm) 495mm 595mm 595mm
Distance Spindle to Base (mm) 1000mm 1050mm 1050mm
Distance from Spindal Centre to 380 (max) 320 (max) 320 (max)
Pillar Surface
Table Travel 500 mm 480 mm 480 mm
Spindle Nose MT-4 MT-4 MT-4
Spindle Travel (mm) 250mm 250mm 300mm
Range of Spindle Speed (RPM) 60 -2000 70 -2000 70 -2000
No. of Spindle Speed 8 8 8
Table Size (mm) 490 x 490mm 410x410mm 410x410mm
Base size (Machined area) (mm) 820 x 490mm 440 x715mm 440 x 715mm
V-Belt Section (mm) B-74 B-59 B-59
Overall Height With Guard (mm) 1840mm 1860mm 1860mm
Main Electrical Motor 2H.P 1.5 H.P 1.5 H.P
Weight (Approx) 500 kgs 325 kgs 325 kgs
