Square Hard Guide Way Flat Bed Lathe (CJK-6130)

Model : CJK-6130

Silent Features

  • CJK6130 is a small accurate flat bed lathe. It is suitable for massive production of meter, high accurate electric device & munitions.
  • High accurate bearing provide high accuracy and high speed for the spindle unit. Ball screw highly increase the accuracy and durability.
  • Integral protection design highly increase the speed of each axis and cleanness of guide way. (Optional Features: Collect, 3 Jaws Chuck Manual, Hydraulic Hollow Chuck)
ModelsCJK6130
Maximum Swing Over BedØ 275mm
Maximum Swing Over SolidØ 200mm
Maximum Swing Over SolidØ 125mm
Maximum Machining Length with Hydraulic Chuck270mm
Maximum Machining Length with Collect (Optional)360mm
Collect Size (Optional)Ø 44mm
Spindle Taper HoleØ 48mm
Max. Diameter of Bar with Manual ChuckØ 37mm
Max. Diameter of Bar with Hyd. Hollow ChuckØ 27mm
Max. Diameter of Bar with Hyd. Solid ChuckNone
Spindle TypeA2-5
Spindle Speed Range50-3000rpm
Spindle Shift ModeInverter
Main Moto Power4 Kw
Chunk TypeHydraulic Solid (AUTOGRIP-Taiwan)
Chunk Size160mm
Rapid Traverse Speed on X Axis8m/min
Rapid Traverse Speed on Z Axis10m/min
Servo Motor Torque on X Axis4Nm
Servo Motor Torque on Z Axis6Nm
X Axis Travel280mm
Z Axis Travel390mm
Guide Way TypeHardened Box Guide Way
Turret Type4 Station Electric Tool Post + 2 Slot Gang Tool Holder
Turret Change Time9071.2-18072.0 - 27072.8 Sec
Turning Tool / Boring Bar Size20 x 20mm / Ø20mm
Tail stock TypeManual Tail Stock
Tail stock Sleeve Diameter/Travel054/150mm
Tail Stock Sleeve TaperMT4
Weight1200KG
Dimension (L*W*H)1560*1130*1550mm
