Description
PARTICULARS / MODEL |
E3-IN-1/1320 |
| Max. Shearing Width | 1320mm |
| Max. Shearing Thickness | 3.0mm |
| Shearing Angle | 2° |
| Number of Stroke | 30/min. |
| Back Gauge Range | 450mm |
| Height of Work Table | 760mm |
| Max. Bending Width | 1320mm |
| Max. Bending Thickness | 2.0mm |
| Max. Rolling Width | 1500mm |
| Max. Rolling Thickness | 2.5mm |
| Min. Rolling Diameter | 90mm |
| Motor Power | 3kW |
| Packing Dimension | 2540x1450x1970mm |
| Net/Gross Weight | 2300/2800Kgs. |
Features
- Ideal Combination of Shearing, Brake & Rolling with Strong Structure
- For the Rolling, the processing for the taper rolling is very easy
- For shearing & bending, both can achieve single stroke and continuous stroke
- The back gauge adopt data control system, the adjustment is quickly and exactly
