Hydraulic Surface Grinding Machine : HSG4523A+

615,500.00

  • Grinding Capacity.:450 x 230 x 330mm
  • T-Slot: 12 x 1 mm x no
  • Spindle Speed :2850 r/min

Quantity :

Share on:

SKU :- HSG4523A+ Category :-

Specification

Specification

Model HSG4523A+
Grinding Capacity: LXWXH 450 x 230 x 330mm
Longitudinal table travel 500mm
Cross table travel 250mm
Max. Distance from the spindle centre To the worktable surface 430mm
Safety load of bench (in max) 100 Kg
Table size 450 x 230mm
T-slot 12 x 1 mm x no.
Bench speed 3-23 m/min
Cross auto feed 0.6-10 mm / Div
Cross rapid feed 144
Cross handwheel per Graduation 0.002 mm
Cross handwheel per Revolution 0.15 mm
Grinding Wheel size( DXWXd) 200 x 16 x 32mm
Spindle Speed 2850 r/min
Max. Movement of Vertical mechanism 430mm
Vertical fine adjustment revolution 0.15mm
Vertical per fine adjustment graduation 0.002mm
Spindle motor 1.1 Kw
Overall dimensions: (LXWXH) 1150 x 1180 x 1800mm
Net Weight / Gross Weight 1300 / 1500 Kgs
