Slant Bed Turning Center (C320K)

Slant Bed Turning Center (C320K)
Models C320K
Maximum Swing Over Bed Ø 320mm
Maximum Swing Over Solid Ø 140mm
Maximum Machining Length with Hydraulic Chuck 245mm
Maximum Machining Length with Collect (Optional) 250mm
Collect OD/ID (Optional) Ø 56/48mm
Spindle Taper Hole Ø 52mm
Maximum Bar Diameter with Hydraulic Hollow Chunk Ø 38mm
Maximum Bar Diameter with Hydraulic Solid Chunk None
Spindle Head Type A2-5
Spindle Speed Range 60-5000rpm
Spindle Shift Mode Servo
Spindle Rated Torque 24Nm
Main Moto Power 3.7Kw
Spindle Moto Maximum Speed Range(30 Min) 5.5Kw
Chunk Type Hydraulic Solid (AUTOGRIP-Taiwan)
Chunk Size Ø 160mm
Rapid Traverse Speed on X Axis 18m/min
Rapid Traverse Speed on Z Axis 18m/min
Servo Motor Torque on X Axis 6Nm
Servo Motor Torque on Z Axis 6Nm
X Axis Travel 320mm
Z Axis Travel 300mm
Guide Way Type Linear Guide Way (PMI/HIWIN Taiwan)
Turret Type Gang Type
Turning Tool / Boring Bar Size 20 x 20mm / Ø20mm
Chips Conveyor (Optional) Hinge Belt
Weight 1500KG
