Hydraulic Surface Grinding Machine : HSG10040A+

1,610,000.00

  • Grinding Capacity.:1000 x 400 x 430mm
  • T-Slot: 18 x 3 mm x no.
  • Spindle Speed :1450 r/min

Quantity :

Share on:

SKU :- HSG10040A+ Category :-

Specification

Specification

Model HSG10040A+
Grinding Capacity: LXWXH 1000 x 400 x 430mm
Longitudinal table travel 1020mm
Cross table travel 440mm
Max. Distance from the spindle centre To the worktable surface 580mm
Safety load of bench (in max) 400 Kg
Table size 1000 x 400mm
T-slot 18 x 3 mm x no.
Bench speed 0-26 m/min
Cross auto feed 0.5-20 mm / Div
Cross rapid feed
Cross handwheel per Graduation 0.02 mm
Cross handwheel per Revolution 4 mm
Grinding Wheel size( DXWXd) 350 x 32 x 127mm
Spindle Speed 1450 r/min
Max. Movement of Vertical mechanism
Vertical fine adjustment revolution 0.04mm
Vertical per fine adjustment graduation 0.001mm
Spindle motor 5.5 Kw
Overall dimensions: (LXWXH) 2260 x 1790 x 1917mm
Net Weight / Gross Weight 3800 / 4200 Kgs
