Box type Geared Drive – Fine Feed

Model : ZAY7025FG...
    Milling and Drilling Machine combine in India to mill, drill, tapping, boring and roaming
  • Gear – driven and Square column
  • Milling, drilling, tapping, boring and roaming
  • Head swivels ± 90° vertically
  • Micro feed precision
  • Adjustable gibs on table precision
  • Strong rigidity power cutting and precise positioning.
MODELZAY7025FGZAY7032FGZAY7040FGZAY7045FG
Drilling capacityø25mmø32mmø40mmø45mm
Face milling capacityø63mmø63mmø80mmø80mm
End milling capacityø20mmø20mmø32mmø32mm
Max. Distance from spindle nose to table445mm450mm450mm450mm
Min.distance from spindle axis to column203mm260mm260mm260mm
Spindle travel85mm130mm130mm130mm
Spindle taperM.T.3M.T.4M.T.4M.T.4
Step of spindle speed6666
Range of spindle speed 50Hz95-1420 r.p.m80-1250 r.p.m80-1250 r.p.m80-1250 r.p.m
Swivel angle of headstock (Vertically)90°90°90°90°
Table size520x160mm800x240mm800x240mm800x240mm
Forward and backward travel of table140mm175mm175mm175mm
Left and right travel of table290mrn500mrn500mrn500mrn
Motor power0.37KW0.75KW1.1KW1.5KW
Net weight180kgs/240kgs320kgs/370kgs320kgs/370kgs323kgs/373kgs
Packing size (LxWxH)680x750x1000mm770x880x1160mm770x880x1160mm770x880x1160mm

Standard Accessories :

  • Allen wrench
  • Wedge
  • Tie Rod
  • Drill Chuck
  • Milling cutter holder
  • Mill Chuck
  • Working Lamp
  • Coolant System
  • Machine Stand
  • Changing Sleeve
  • Parallel Vise
  • Boring Bar.
