Drilling and Milling Machine Auto Feed

Model : Z5032C-1
    Milling cum Drilling Machine in India for milling and drilling both activities along with tapping.
  • Milling, drilling, and tapping
  • Spindle speed step-change cyclically ,spindle auto feeding and cyclic change of feeding speed
  • Head swivels ± 360° Horizontally
  • Super high column
  • Precision micro feed
  • Positive spindle lock
  • Distinct auto device for releasing tools, operate very easily
  • Gear driven, lower noise
Max.drilling capacityø32mmø40mmø45mm
Spindle taperM.T.4M.T.4M.T.4
Spindte travel130mm130mm130mm
Step of spindle speed666
Range of spindle speed 50Hz80-1250 r.p.m80-1250 r.p.m80-1250 r.p.m
Step of spindle auto-feeding666
Range of spindle auto-feeding amount0.06 -0.30mm/r0.06 -0.30mm/r0.06 -0.30mm/r
Min.dislance from spindle axis to column290mm290mm290mm
Max.distance from spindle nose to worktable700700700
Max.distance from spindle nose to stand table1125mm1125mm1125mm
Max.travel of headstock250mm250mm250mm
Swivel angle of headstock (horizontal)360°360°360°
Max. travel of worktable bracket600mm600mm600mm
Worktable size of availably730 x210mm730 x210mm730 x210mm
Swivel angle of table horizontally360°360°360°
Size of stand workable of availability417x416417x416417x416
Worktable travel ((X/Y)500 / 205mm500 / 205mm500 / 205mm
Vertical travel of worktable570mm570mm570mm
Motor Power0.75KW1.1KW1.5KW
speed of motor1400 r.p.m.1400 r.p.m.1400 r.p.m.
Net weight470kgs/530Kgs470kgs/530Kgs470kgs/530Kgs

Standard Accessories :

  • Wedge
  • Tie Rod
  • Drill Chuck
  • Milling cutter holder
  • Mill Chuck
  • Working Lamp
  • Coolant System
  • Changing Sleeve
  • Parallel Vise
  • Boring Bar
  • Auto Tapping Arrangement
