Light Duty All Geared Lathe – PRH-175 & PRH-200

Model : PRH Series

Features:

  • High Tensile Casting
  • Head Stock Latest Design
  • Bed & Spindle are Hardened & Ground
  • There are three models in this category.
  • This device is featured with gear box for improved, fast and flawless performance.
  • It is highly suitable for handling relatively hard materials that is not possible in light duty lathes.
  • It is also known for its high speed performance, precision in machining, robust construction, etc which make this device stay consistent for long run production needs.
  • We have applied modern aspects while designing the machining platform to support easy material feed and uninterrupted machining.
  • It stays very efficient for investing for accompanying long term workshop activities.
  • For getting excelling performance, consumers can choose suitable optional accessories available with us.
ModelsPRH-175PRH-200
Height of Center(mm)175200
Max Swing over bed (mm)350400
Max Swing over Slide (mm)190240
Width of Bed(mm)242280
Spindle
Bore (mm)4051
NoseLoo TypeLoo Type
Spindle No 8 (RPM)48 to 153548 to 1535
Travel (MM)
Cross Slide180210
Top Slide125125
Quil Dia / Travel50 / 12550 / 125
Other
Lead Screw TPI44
Tail Stock Sleeve MT33
Power Required (H.P.)22

Admit Between Centers

Bed LengthA. B. C
6'1000 mm
7'1200 mm

Gear Box with Lead Screw & Feed Shaft Separate

Standard Accessories :

  • Chuck Plate
  • Gear Set
  • Centre Adaptor
  • Dead Centres
  • Dial Indicator
  • Square Tool Post
  • Tool Post Key

Optional Accessories :

  • Steady Rest
  • Follow Rest
  • Face Plate Electrical Fittings
  • True Chuck & Dog Chuck
  • Machine Lamp

  • Quick Change Tool Post Tapper Turning Attachment
  • Coolant Pump with Tank & Fittings
  • Rear Tool Post
  • Norton Gear Box
