Light Duty Lathe (Super Model)

Model : LD Series


  • High Tensile Casting
  • Latest Design Head Stock
  • Hardened & Ground Bed & Spindle
  • Our light duty equipmentis designed in standard model and super model.
  • It is easy to accommodate this equipment in moderate workshops and stays a very good investment for small scale metal industries.
  • Suitable for applying in variety of industrial machining processes.
  • Perfect workshop tool for engineering industry.
  • Lots of metal cutting works can be tried out using this equipment.
  • It serves the purpose of transforming metal work materials into different shapes over pre-determined dimensions.
  • It is easy to operate and eradicates many complexities which are present in manual metal shaping.
  • Maintenance is absolutely hassle free as all the machine components are made of corrosion resistant and higher grade metals.

Super Model

ModelsLD 165LD 175
Height Of Centre (mm)165175
Width of Bed (mm)238238
Max Swing over bed (mm)330350
Max Swing over Slide (mm)180200
Spindle Bore (mm)4040
Spindle Nose8 TPI8 TPI
Spindle Speed 8 (R.P.M)30-82530-825
Cross Slide Travel (mm)225225
Lead Screw TPI4 TPI4 TPI
Tail Stock SleeveMT-3MT-3
Power Required (H.P.)11

Super Model Admit Between Centers

LengthA. B. C
4.6'650 mm
5.3'875 mm
6'.0''1050 mm

Standard Accessories :

  • Chuck Plate
  • Gear Set
  • Centre Adaptor
  • Dead Centres
  • Dial Indicator
  • Square Tool Post
  • Tool Post Key

Optional Accessories :

  • Steady Rest
  • Follow Rest
  • Face Plate
  • Electrical Fitting
  • True Chuck & Dog Chuck
  • Quick Change Tool Post
  • Tapper Turning Attachment
  • Coolant Pump with Tank & Fittings
  • Machine Lamp
  • Rear Tool Post
  • Norton Gear Box
  • Key Way Milling Attachment
  • Tool Post Grinder
